Lineare Single-lever mixer with 3-way diverter
Tactile control to effortlessly switch between 3 shower or bath functions: the GROHE Lineare single-lever mixer trim set
Key Features
final installation for
- GROHE Rapido SmartBox (35 604)
- GROHE SilkMove 46 mm ceramic cartridge
- GROHE Long-Life finish
- GROHE FastFixation escutcheon with covered shaft sealing and covered fixing
- metal escutcheon, retroactively 6° adjustable
- 3-way diverter
outlet A = 27 l/min, outlet B = 27 l/min, outlet C = 27 l/min
- without roughing-in-set
Technical Product Information
CAD Data
| Pos.-nr. | Prod. description | Spare part-nr. |
|---|---|---|
| * Optional accessories | ||
| 1 | Lever | 46988AL0 |
| 2 | Diverter knob, round | 48447AL0 |
| 3 | Escutcheon | 49105AL0 |
| 4 | Mounting plate | 49094000 |
| 5 | Cap | 09038AL0 |
| 6 | Cartridge | 46048000 |
| 7 | Diverter | 48448000 |
| 8 | Seal | 48360000 |
| 9 | Temperature limiter | 46308000* |
| 10 | Universal extension set single-lever mixers, 25 mm | 14056000* |
| 11 | Universal extension set single-lever mixers, 50 mm | 14057000* |
